How they Work
SA series electric cylinders offer high thrust force and precise, instantaneous machining control.
The versatility of the electric system makes them the ideal solution in a wide variety of industrial processes.
High Flexibility of Applications
Bending
Drawing
Keying
Assembly
Clinching
Trimming
Chamfering
Marking
Straightening
Riveting
Pressing
Cutting
Compressing
Why choose Alfamatic electric cylinders
Active control of the Process
Constantly controlled movements in acceleration, speed and position. Active position control ensures high accuracy at the stopping point, which can be improved by using an external micrometer position transducer. Learn more
High productivity
Minimizes stem excursion, speeding up machining cycles and reducing time.
Application flexibility
Easily program complex machining cycles with saved and independent parameters.
LONG DURATION
The combination of advanced mechanical components ensures prolonged durability even under stress.
Low management cost
Energy consumption is limited to the processing stage only, optimizing energy efficiency.
Versions and Characteristics
SA 1-5
Atuator with ball recirculation technology.
Available in 3 models with thurst forces from:
1 kN
2 kN
5 kN
SA 10-180
Actuator with
planetary roller technology.
Available in 8 models with thrust forces from:
10 kN
15 kN
25 kN
50 kN
100 kN
120 kN
150 kN
180 kN
SA 200-300
Actuator with
heavy duty planetary roller technology.
Available in 2 models with thrust forces from:
200 kN
300 kN
The components of the kit
The chain of command and control consists of 4 inseparable elements.
Fundamental to the synergy between the various elements, which are designed to interact optimally with each other.
- Electric Cylinder
Complete with motor, temperature sensor, load cell and absolute encoder, to measure the force and position of the rod.
- Drive-unit
It drives the brushless motor of the cylinder and controls the position of the rod.
- Press-Right
It checks, in real time, the force and instantaneous position of the cylinder.
- Cables
All the cables needed to connect the different components of the system.
Accessories and Options
External Load Cell
The external HPT load cell allows precise measurement of low forces, further extending the versatility of Alfamatic electric cylinders.
External Micrometric Probe
It allows to measure, with micrometric precision, the true position of the tool with respect to a reference point on the piece, eliminating the inaccuracies due to the play and deformations of the structure.
C Frame
Low-bending monolithic steel structure.
Ground mold support plate made of steel.
Electric Cabinet
Pre-wired, containing:
- Drive-unit
- General on-off switch with door lock
- Magnetic thermal protection switches
- Redundant power supply switches
- Cooling system
- Terminal block for connection to main panel
Lubricating Grease
Specific lubricating grease for presses with planetary roller screws.
Grease Pump
It allows, through the greasing hole, the addition of grease inside the electric actuator nut.
Range and Technical Specifications
1 kN
0,5% F.S.
280 mm
20 Mio
250 mm/s
0.7°
External Load Cell
Standard
0,04 mm
Direction of Measurement bi-directional (compression and traction)
Recirculating Balls
Press-Right System
2kN
0,5% F.S.
280 mm
20 Mio
250 mm/s
0.7°
External Load Cell
Standard
0,04 mm
Direction of Measurement bi-directional (compression and traction)
Recirculating Balls
Press-Right System
5 kN
0,5% F.S.
280 mm
20 Mio
250 mm/s
0.7°
External Load Cell
Standard
0,04 mm
Direction of Measurement bi-directional (compression and traction)
Recirculating Balls
Press-Right System
10 kN
0,5% F.S.
300 / 420 mm
30 Mio
250 mm/s
0.7°
Internal Load Cell
Standard
0,01 mm
Direction of Measurement bi-directional (compression and traction)
With Satellite Rollers
Press-Right System
15 kN
0,5% F.S.
300 / 420 mm
15 Mio
220 mm/s
0.7°
Internal Load Cell
Standard
0,01 mm
Direction of Measurement bi-directional (compression and traction)
With Satellite Rollers
Press-Right System
25 kN
0,5% F.S.
300 / 420 mm
15 Mio
140 mm/s
0.7°
Internal Load Cell
Standard
0,01 mm
Direction of Measurement bi-directional (compression and traction)
With Satellite Rollers
Press-Right System
50 kN
1% F.S.
250 / 420 mm
30 Mio
250 mm/s
0.7°
Internal Load Cell
Standard
0,01 mm
Direction of Measurement bi-directional (compression and traction)
With Satellite Rollers
Press-Right System
70 kN
0,7% F.S.
250 / 420 mm
15 Mio
180 mm/s
0.7°
Internal Load Cell
Standard
0,01 mm
Direction of Measurement bi-directional (compression and traction)
With Satellite Rollers
Press-Right System
100 kN
0,5% F.S.
250 /420 mm
10 Mio
100 mm/s
0.7°
Internal Load Cell
Standard
0,01 mm
Direction of Measurement bi-directional (compression and traction)
With Satellite Rollers
Press-Right System
120 kN
0,5% F.S.
250 / 420 mm
30 Mio
125 mm/s
0,7°
Internal Load Cell
Standard
0,01 mm
Compression
With Satellite Rollers
Press-Right System
150 kN
0,5% F.S.
250 / 420 mm
20 Mio
100 mm/s
0,7°
Internal Load Cell
Standard
0,01 mm
Compression
With Satellite Rollers
Press-Right System
180 kN
0,5% F.S.
250 / 420 mm
15 Mio
83 mm/s
0,7°
Internal Load Cell
Standard
0,01 mm
Compression
With Satellite Rollers
Press-Right System
200 kN
0,5% F.S.
420 mm
30 Mio
150 mm/s
1°
Internal Load Cell
Standard
0,01 mm
Traction
With Satellite Rollers
Press-Right System
300 kN
0,5% F.S.
420 mm
30 Mio
100 mm/s
1°
Internal Load Cell
Standard
0,01 mm
Traction
With Satellite Rollers
Press-Right System
